150mm Flexible Copper PVC Covered Earth Grounding Wire Cable Green/Yellow
Henan Hongda Cable Co., Ltd.- Type:Insulated
- Conductor Type:Stranded
- Application:Underground, Construction
- Conductor Material:Copper
- Sheath Material:No Sheath
- Insulation Material:PVC
Base Info
- Model NO.:Flexible Grounding Cable
- Material Shape:Round Wire
- Range of Application:Construction, Underground, House Wire
- Certification:ISO9001, CCC, SGS
- Brand:Hongda
- Voltage Rating:600 Volts
- Flame Retardant:IEC 60332-1-2
- Max Conductor Temperature:-25c , +70c
- Conductor:IEC 60228,1
- Transport Package:Package in Roll or Reel or Drum
- Specification:0.5mm2 to 240mm2
- Trademark:Hongda Cable
- Origin:China
- HS Code:8544492900
- Production Capacity:900km,Month
Description
Construction dataSize norminal Diameter norminal of condcutor Insulation Thickness Overall diameter Mass Approx. Weight (mm2) (mm) (mm) (mm) (kg/km) 0.5 0.9 0.6 2.10 9 0.75 1.15 0.6 2.35 11 1 1.25 0.6 2.45 14 1.5 1.55 0.7 2.95 20 2* 1.7 0.8 3.30 25 2.5 1.97 0.8 3.57 32 4 2.5 0.8 4.10 46 6 3.10 0.8 4.70 64 10 4.30 1.0 6.30 116 16 5.40 1.0 7.40 175 25 6.80 1.2 9.20 265 35 7.85 1.2 10.25 364 50 9.30 1.4 12.10 520 70 11.25 1.4 14.05 720 95 12.50 1.6 15.70 890 120 14.00 1.6 17.20 1190 150 15.50 1.8 19.10 1500 185 17.70 2.0 21.70 1790 240 20.00 2.2 24.40 2390 (*) Data subject to change without notice
A: Roll of 100 m
B: Reel of 1500 m.
C: Reel of 1000 m.
D: Reel of 500 m.
E: Multiple Reels of 1000 m.
Z - Length to the client's requirement.
