BS 6622 Single Core Armoured 6.6kv XLPE Stranded Aluminium Conductor

YIFANG ELECTRIC GROUP INC.
  • Application：Construction, Underground
  • Voltage：Low and Medium Voltage Cable
  • Current：DC & AC
  • Insulation Material：XLPE
  • Sheath Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：6.6kv cable BM47
  • Wire Core Material：Bare Copper Wire
  • Certification：ISO, CCC, CE, RoHS, UL, VDE
  • Model：YJV
  • Brand：Yifang
  • Option Conductor：Aluminum
  • Transport Package：Wooden or Wooden-Steel Drum
  • Specification：multicores
  • Trademark：Yifang Cable
  • Origin：Zhengzhou, China
  • HS Code：8544601200
  • Production Capacity：300km,Month

Description

Size mmsq

Minimum Average Thickness of Insulation mm

Nominal Area of Copper Tape Screen

Size

Current Ratings

Short circuit ratings

Laid in ground
Amps

Drawn into ducts
Amps

Laid in air
Amps

One second short circuit rating of conductor
KA

One second short circuit rating of copper per core
Ka

70

210

210

240

6.3

-

95

250

245

295

8.5

-

120

280

275

335

11.0

Typically

150

315

300

380

13.5

Less

185

355

335

435

17.0

Then

240

405

380

510

22.3

1kA

300

455

420

580

28.0

-

400

510

455

670

36.6

-

500

570

500

770

46.2

-

630

640

550

880

58.3

-
